CHANNEL-L5860-P
Describe
1. Acoustic Linear led light dimension: L1160×W58×H60mm.
2. Installation: Recessed mounted.
3. Finsh Color: Black RAL9005/ White RAL 9016.
4. Optics: 120° Opal diffuser, UGR＜27.
5. Distribute: direct.
6. Life Span: L80B50 50000 hours.
7. Power supply: No dimmer driver or DALI dimmer driver.
8. IP 20.
9. material: Aluminum+Plastic PMMA.
- Specifications
| Model | CHANNEL-L5860-P |
| Power | 36W |
| Product Length | 590/ 1160/ 1540/ 1730/ 2490mm |
| Material | Aluminum+PC |
| Input Voltage | AC 200-240V or AC 100-277V (50/60HZ) |
| LED Source | LUMILEDS (SMD2835) |
| CRI | 80+ |
| Efficacy | 100-105 lm/W |
| Luminous flux | 3600-3780 lm |
| Uniform Glare Value | UGR＜27 |
| Distribute | direct |
| Beam Angle | 120° |
| Driver | CE or ULdriver |
| Driver PF | ＞0.95 |
| Dimming | NO Dimming or DALI Dimming or 0-10V Dimming |
| Warranty | 5 years |
| Installation | Recessed Mounting |
| IP Rating | IP 20 |
| Application | Office/ Home/ School/ Hotel. |
Product Specifications Download
CHANNEL-L5860-P.pdf
